1734-EP24DC
Description
| I/O Module Capacity | 4-17 modules, depending on current rating of each module |
| Input Voltage Rating | 24V dc nominal 10…28.8V dc range |
| Field Side Power Requirements | 24V dc (+20% = 28.8V dc maximum) @ 400 mA maximum |
| Inrush Current | 6 A maximum for 10 ms |
| Indicators | 1 Green Field Power Status Indicator
1 Green 5V System Power Indicator |
| POINTBus Output Current | Horizontal mounting –
1 A at 10…19.2V input; 1.3 A at 19.2…28.8V input Vertical mounting – 1 A at 10…28.8V input |
| Input Overvoltage Protection | Reverse polarity protected |
| Interruption | Output voltage will stay within specifications when input drops out for 10ms at 10V with maximum load. |
| Module Location | Between I/O modules in 1734 system
Breaks field power bus |
| Limitations | Use with POINT I/O Adapters only |
| Dimensions millimeters
inches |
76.2H x 25.4W x 133.4L mm
(3.00H x 1.00W x 5.25L in) |
| Weight | 0.12 kg (0.27 lb) |
| Terminal Base Screw Torque | 0.6 Nm (7 lb-in) |
