| Manufacturer |
Rockwell Automation |
| Location |
1746 Chassis, Left Side |
| Input Voltage Range |
19.2-28.8 VDC |
| Module Type |
Power Supply |
| Series |
SLC 500 |
| Part Number/Catalog No. |
1746-P3 |
| Brand |
Allen-Bradley |
| Nom Input Voltage |
24VDC |
| Typical line power requirement |
90 VA |
| Inrush Current |
20 A |
| Isolation Voltage |
600V ac RMS for 1 s (version B or later) |
| Current Capacity |
3.6 A at 5V dc and 0.87 A at 24V dc |
| Hold Up time |
5 ms (full load); 1000 ms (no load) |
| Fuse protection |
1746-F3 or equivalent |
| Temperature, ambient operating |
0…60 ??C (32…140 ??F) |
| Current capacity deration |
5% above 55 ??C (131 ??F). |
| Input Voltage |
24 Volts DC |
| Input Power |
61 Watts |
| Backplane Current (5 Volts) |
3.6 Amps |
| Backplane Current (24 Volts) |
0.87 Amps |
| Frequency |
DC |
| Weight |
2.5 pounds (1.1 kilograms) |
| Dimensions |
5.5 x 2.9 x 5.7 inches |
| Operating Temperature |
0 to 60 degrees Celsius |
