193-EOS-SCS
IP65-rated industrial operator station with diagnostic LEDs and Copy Cat™ configuration transfer. Features motor control buttons (Start/Stop/Speed/Reset) and blink-code fault identification for 50+ error types
Description
| Parameter | Value |
|---|---|
| Model Number | 193-EOS-SCS |
| Product Type | Operator Station (E300/E200 Series) |
| Key Functions | Start/Stop, Speed Control, Local/Remote, Reset, Navigation (Up/Down/Enter) |
| LED Indicators | Power (Green/Red), Trip/Warn (Red/Yellow) |
| Diagnostic Capabilities | 50+ fault codes (Current/Voltage/Control/Analog categories) |
| IP Rating | IP65 (Dust-tight, water-jet resistant) |
| Configuration Feature | Copy Cat™ (Read/Write configurations via button sequences) |
| Mounting Requirement | Type 4X Enclosure (NEMA 4X equivalent) |
| Safety Compliance | NFPA 70E (Arc-flash hazard prevention) |
| Control Buttons | Start FWD/REV, Speed 1/2, Stop, Reset, Escape, Up/Down, Select, Enter |
| Fault Identification | Blink-code diagnostics (e.g., 0.4 = Stall, 1.2 = Over Voltage L-L) |
| Communication Protocol | Not specified (Local I/O implied) |
| Power Source | Not specified (Typically 24V DC/110-230V AC) |
| Operating Environment | Industrial (Contaminant-free enclosure required) |
| Certifications | CE, RoHS |
