6DL1193-6AG20-0AA0 Siemens
SIMATIC ET 200SP HA, bus adapter BA LC/RJ45, Media converter FOC/CU 1x LC FO connection and, 1x RJ45 connection for PROFINET
Description
1. Product Introduction
The 6DL1193-6AG20-0AA0 is a SITRANS TH400 temperature transmitter from Siemens, designed for industrial temperature measurement and signal conditioning. It converts signals from RTDs (Pt100, Pt1000) or thermocouples (Type J, K, etc.) into standardized 4–20 mA or HART/Profibus PA outputs, enabling seamless integration with control systems.
2. Key Features
- Input Types: Supports RTDs (2/3/4-wire) and thermocouples (multiple types).
- Output Options:
- 4–20 mA analog output (HART-enabled).
- Profibus PA (for digital communication).
- Accuracy: ±0.1% of span (high-precision measurement).
- Display: Optional LCD display for real-time temperature monitoring.
- Robust Design:
- IP66/IP67 protection for harsh environments.
- -40°C to +85°C operating range.
3. Applications
- Process industries (chemical, oil & gas, pharmaceuticals).
- HVAC systems and power plants.
- Food & beverage production (sanitary applications).
4. Technical Specifications
- Power Supply: 10.5–42 V DC (4–20 mA models).
- Communication: HART 7/Profibus PA.
- Certifications: ATEX, IECEx, SIL 2/3 (safety compliance).
